The difference between pneumatic oil purifier and centrifugal oil purifier

Pneumatic oil filters and centrifugal oil filters are two types of industrial oil purification equipment with completely different operating principles. Their main differences are reflected in many aspects, such as their operating principles, filtration effects, and applicable scenarios.

1. Working Principle

• Pressure Oil Filter: Think of it as a "super-fine sieve." A pump forces contaminated oil under pressure through a filtration medium (like filter paper or a specialized cartridge). The pores in this "sieve" are microscopic (down to the micron level), which physically traps solid particles larger than the pores, resulting in clean oil. Its core mechanism is direct interception.




• Centrifugal Oil Separator: Operates like a "washing machine spin cycle." It spins the contaminated oil at high speeds inside a rotating drum, generating centrifugal forces thousands of times greater than gravity. Due to their different densities (water > oil > most solids), the components separate into layers: the heaviest solids are forced to the outermost wall, water forms a middle layer, and the cleanest oil collects innermost layer. These separated layers are then discharged through individual outlets. Its core mechanism is separation by density.

2. Filtration Focus

• Pressure Oil Filter: Excels at Removing Solids. Its primary goal is to eliminate solid particles. It is an essential tool for applications demanding extremely high oil cleanliness (e.g., in precision hydraulic systems where a single tiny particle can clog a valve and cause failure). It can remove some water, but this is not its strength.




• Centrifugal Oil Separator: Excels at Removing Water. Its primary goal is to separate water. It is highly effective for purifying oil that has significant water contamination from leaks, condensation, etc. (e.g., machine tool coolant, marine fuel). It also removes a large portion of solid impurities simultaneously.

3. Operational & Maintenance Costs

• Pressure Oil Filter: The main cost is the filter elements/cartridges, which are consumable items requiring regular replacement. If the oil is very dirty, replacements can be frequent, leading to higher ongoing consumable costs.




• Centrifugal Oil Separator: It has no consumable filter media to ｒｅｐｌａｃｅ. The primary costs are electricity (to power the high-speed motor) and periodic mechanical maintenance (e.g., replacing seals, bearings on the rotor). Although individual maintenance events might be more expensive, the total long-term operating cost is often lower.

How to Choose?

The choice between these two systems depends entirely on your primary objective and the condition of your oil:

• Choose a Pressure Oil Filter if your primary concern is solid particle contamination and you require exceptionally high cleanliness levels (e.g., specific NAS classes).




• Choose a Centrifugal Oil Separator if your main problem is high water content (free or emulsified) and your goal is bulk water removal, with less emphasis on achieving ultra-fine particulate filtration.




• For complex cases involving both significant water and a requirement for extreme particulate cleanliness, the ideal solution is often a combination: Use a centrifugal separator first to remove the bulk water and solids, followed by a pressure filter for final "polishing." This two-stage approach dramatically extends the life of the final filter cartridges and achieves the best possible purification result.

In summary, the Pressure Filter is your "Precision Sieve" for solids, while the Centrifugal Separator is your "Powerful Dehydrator" for water. Selecting the right tool for your primary challenge is the key to an effective and efficient operation.
